| Product Description |
| Thread Diameter: 5.58mm(0.220'') | Application |
| Shank Diameter: 4.3mm(0.169'') | Insulation&Membrane Fixing |
| Head Diameter: 11.2mm(0.435'') |
| Head Type: T30 Torx Pan Head | Advantage |
| Material | Sharp drill point for faster drilling speed. |
| Heat Treated Steel C1022 | Heavier shank diameter generate more torque. |
| Surface Treatment | Plates & Accessories |
| Standard: CR-10 Corrosion Resistant Coating | Use 3" (76 mm) steel plates or plastic plates, depending upon the application. |
| Customized: 500-2000H NSS/5-30 Cycles of Kesternich |
|
|
| Model No. | Size | Thread | Packing | Weight(Kgs) |
| TSR-TPT1201 | 1-5/8'' | Full | 1000PCS/Bucket | 5.71 |
| TSR-TPT1202 | 2-1/4'' | Full | 1000PCS/Bucket | 8.09 |
| TSR-TPT1203 | 3'' | 3'' | 1000PCS/Bucket | 11.32 |
| TSR-TPT1204 | 4'' | 3'' | 1000PCS/Bucket | 13.2 |
| TSR-TPT1205 | 5'' | 4'' | 1000PCS/Bucket | 16.35 |
| TSR-TPT1206 | 6'' | 4'' | 1000PCS/Bucket | 18.86 |
| TSR-TPT1207 | 7'' | 4'' | 1000PCS/Bucket | 22.64 |
| TSR-TPT1208 | 8'' | 4'' | 1000PCS/Bucket | 23.59 |
