| Product Description |
| Thread Diameter: 6.22mm(0.245'') | Application |
| Shank Diameter: 4.8mm(0.190'') | Insulation&Membrane Fixing |
| Head Diameter: 11.2mm(0.435'') |
| Head Type: #3 Phillips Flat Head | Advantage
|
| Material | Sharp drill point for faster drilling speed. |
| Heat Treated Steel C1022 | Heavier shank diameter generate more torque. |
| Surface Treatment | Plates & Accessories |
| Standard: CR-10 Corrosion Resistant Coating | Use 3" (76 mm) steel plates or plastic plates, depending upon the application. |
| Customized: 500-2000H NSS/5-30 Cycles of Kesternich |
|
| Model No. | Size | Thread | Packing | Weight(Kgs) |
| TSR-FHT141A | 1-1/4'' | Full | 1000PCS/Bucket | 5.44 |
| TSR-FHT141B | 1-3/4'' | Full | 1000PCS/Bucket | 7.26 |
| TSR-FHT1402 | 2'' | Full | 1000PCS/Bucket | 8.16 |
| TSR-FHT1403 | 3'' | Full | 1000PCS/Bucket | 11.79 |
| TSR-FHT1404 | 4'' | 3'' | 1000PCS/Bucket | 15.42 |
| TSR-FHT1405 | 5'' | 4'' | 500PCS/Bucket | 9.96 |
| TSR-FHT1406 | 6''
| 4'' | 500PCS/Bucket | 11.79 |
| TSR-FHT1407 | 7'' | 4'' | 500PCS/Bucket | 13.61 |
| TSR-FHT1408 | 8'' | 4'' | 500PCS/Bucket | 15.42 |
| TSR-FHT1409 | 9'' | 4'' | 500PCS/Bucket | 16.78 |
| TSR-FHT1410 | 10'' | 4'' | 500PCS/Bucket | 18.14 |
| TSR-FHT1411 | 11'' | 4'' | 500PCS/Bucket | 19.95 |
| TSR-FHT1412 | 12'' | 4'' | 250PCS/Bucket | 11.34 |
| TSR-FHT1414 | 14'' | 4'' | 250PCS/Bucket | 13.15 |
| TSR-FHT1416 | 16'' | 4'' | 250PCS/Bucket | 16.78 |
